EGODRIFT Tengu 4020HS 860Kv Goblin 520 Motor (6x32) : 11951
Hand-wound EGODRIFT Tengu 4020HS motor with a kV rating of 860kV for 500-550mm class rc helicopter models such as the SAB iLGoblin 520 - intended for use with 6S LiPo batteries.
SPECIFICATIONS
- Manufacturer: EGODRIFT
- Stator size: 4020
- Motor configuration: 12N10P
- Motor weight: 290g (10.229 oz)
- Wire colour: Copper
- Motor wire type: High temperature copper wire
- Motor wire: 1.5mm
- Motor Kv: 1050 Kv
- Motor shaft: Hardened Steel
- Mounting hole pattern: 4xM3(25)
- Laser Design: EGODRIFT Stickerbomb
- LiPo cells: 6S
- Stator diameter: 40 mm
- Stator height: 20 mm
- Stator lamination: 0.15 mm (+)
- Body Length: 45mm (1.77 inch)
- Diameter: 49.6mm (1.95 inch)
- Idle current: 5.2A
- Maximum Current: 85A (Peak: 110A / 2 seconds)
- Maximum Power: 2040W (Peak: 2640W / 2 seconds)
- Internal resistance: 8.1 mOhm
- Connection: Wire / Gold plated plugs
What's in the box
- 1 x Tengu 4020HS / 860kV Motor
- 3 x Gold Plated Connector, Male
- 3 x Gold Plated Connector, Female
- 4 x Mounting Screws
- 1x Bell securing screw
