Scorpion HK5-4030-715kv : HK5_4030_715

Scorpion HK5-4030-715kv : HK5_4030_715

We introduce the fifth generation of Scorpion's renowned and award winning "HK - Series" motors. The Scorpion "HK5 - Series"

The HK5 Series lives up to and exceeds our standards of the most Powerful and Efficient motors, with market leading Torque per Amp capabilities. In addition, on the HK5 series we focused specifically on motor cooling and motor temperature. With an all new Internal Fan design, combined with our proven external centrifugal fan, we have nearly doubled the amount of airflow passing through the motor. The result is much improved cooling, and cooler operating temperatures.

The HK5-4030-715kv is designed for 570-650mm size helicopters running on 8s-10s, lightweight 700 size helicopters on 8s, or other UAV application requiring up to 6900w of power.

Specifications

• Motor Kv 715KV RPM/Volt
• Weight 428.0 Grams ( 15.09oz)
• Motor Body Dimensions 49.5mm x 62.0mm (1.95" x 2.44")
• External Shaft Dimensions 5.98mm x 38mm (0.235" x 1.50")
• Continuous Current 100 Amps
• Continuous Power 3700 Watts
• Peak Current 180A (2 seconds)
• Peak Power 6900 Watts (2 seconds)
• Max Lipo Cell* 10s
• Stator Diameter 40 mm (1.57 in)
• Stator Thickness 30 mm (1.18 in)
• No. of Stator Arms 12
• No. of Stator Poles 10
• Motor Wind 4T Delta
• Motor Wire 1.6mm

*Higher Cell Count possible with appropriate gear ratio adjustment

Included in the Box

• 1 x HK5-4030 BLDC Motor
• 3 x Female 4mm Connectors
• 3 x Heat Shrink
• 1 x Hardware / Accessory Pack
