Sunnysky M4530R 518KV (Long Shaft) : OSHM-SS-4530-518R-L
Racing Edition Performance motor for RC Helicopter
Specification
- Stator Diameter : 45.5mm
- Stator Thickness : 30mm
- No. of Stator Slots : 12N
- No. of Poles : 10P
- No-Load Current (A/10V) : 2.5A
- Motor Wind : 4+4 Turn Delta
- Motor Resistance : 8.5mΩ
- Max Continuous Current : 125A
- Max Continuous Power : 6000W
- Motor Weight : 543g
- Outside Diameter : 56.3mm
- Shaft Diameter : 6mm
- Body Length : 57mm
- Overall Shaft Length : 55mm
- Mounting Hole and Screws : 30mm, 4 x M4
- Max Lipo Cell : 12S
- Recommended ESC : 200A
- Recommended Helicopter Size : 700-800mm
