SAB Kraken 580 Kit : SG580

TECHNICAL SPECIFICATIONS

• AIRFRAME weight: 1760gr ( with blades, no battery, no electronics )
• Main blade length: 550mm to 600mm
• Tail blade length: 95 to 105 mm
• Main rotor diameter: 1270 mm (with 570 mm blades included)
• Tail rotor diameter: 260 mm (with 95 mm tail blades included)
• Cyclic Servos: mini size 35 mm (standard size 40mm option part H1217-S, H1207-S)
• Tail Servo: standard size 40mm.
• Main Rotor ratio : 11.5 to 8.6 :1 ( 22T included: 9.4:1)
• Tail Rotor ratio : 5.3-4.9:1 ( 23T included: 4.9:1 )
• Typical motor : 4025 series, 6S 1000-1200 Kv, 12S 500-600 Kv Minimum Shaft Length 26mm (Recommended 6mm Shaft Dia)
• Typical speed controller: 6S 120-140 A, 12S 100-130A
• Battery size: 6S 5000/5800 mAh, 12S 2600/3200 mAh.
